Flat Slate
Available Colours
Black, Anthracite, Grey, New Brown, Terracotta, Country Red
This classic flat interlocking concrete tile combines modern design and technical expertise. Available in a choice of 6 distinctive Condron colours and suitable for roof pitches down to 17.5°.
Also available in Mock Bond and Bullnose.
Note: Flat Tiles should be laid in a broken (half) bond pattern and Mock Bond versions in a quarter/three quarter bond pattern.
All Condron Roof Tiles are manufactured to comply with BS EN 490 and should be fitted in accordance with BS5534
Fittings & Accessories Verge
Left hand verge tile
Left and right hand half tiles
Dry verge – Condron Dry Verge system
Continuous dry verge system
Ridges
Universal Angle ridge
High Pitch Angle ridge
Universal Ornamental ridges
Hip
Universal Angle ridge / Hip
Valley
GRP dry fix
Lead
Ventilation
Dry ridge and hip systems
Over-fascia ventilation system
Tile ventilators
Fixings
Nails and clips.
Reference should be made to BS 5534:2014+A2:2018 and any new code of practices in the future. Condron Concrete Roof Tiles are manufactured in compliance with E.N. 490:2011+A1: 2017
Technical Data
Minimum roof pitch*
17.5° at 100 mm headlap*
22.5° at 75 mm headlap*
Minimum headlap
75 mm
Maximum gauge
345 mm
Overall length
420 mm
Overall width
330 mm
Cover width
300 mm
Coverage at maximum gauge
9.7 tiles/m2
Weight per 1000 tiles
5 tonnes
Laid weight at 345mm gauge
48.7 kg/m2
Pallet quantity
180
Batten sizes
38 x 25mm (rafter centres up to 450 mm)
50 x 25mm (rafter centres up to 600 mm)
Tile nails
50 × 3.35 mm aluminium clout head
Tile, eaves & verge clips
Stainless steel
